| + INDUSTRIAL / SEWERAGE SUBMERSIBLE PUMP |
|
|
B-Series
Channel Impeller
Solid Passage: 31 to 323mm
Capacity: 0.01 to 110 m³/min
Head: 2m to 58m
Discharge: 50 to 800mm
Power: 0.4 to 110kw |
|
|
BZ-Series
Channel Impeller
Solid Passage : 80mm
Capacity : 0.1 to 3.6m³/min
Head : 3.5m to 35m
Discharge : 80 to 100mm
Power : 1.5 to 15kw |
|
| |
|
|
BUL Series
Channel Impeller
Solid Passage : 60 to 110mm
Capacity : 0.15 to 12m³/min
Head : 3m to 36m
Discharge : 100 to 250mm
Power : 2.2 to 37kw |
|
|
C-Series
Cutter Impeller
Solid Passage : 21 to 60mm
Capacity : 0.05 to 1.75m³/min
Head : 2m to 17m
Discharge : 50 to 100mm
Power : 0.75 to 15kw
|
|
| |
|
|
PU / PN Series
Vortex Impeller
Solid Passage : 35 to 46mm
Capacity : 0.025 to 0.8m³/min
Head : 2m to 16m
Discharge : 40 to 80mm
Power : 0.15 to 1.5kw |
|
|
PSF Series
Closed Impeller
Solid Passage : 8 to 13mm
Capacity : 0.025 to 0.6m³/min
Head : 1m to 21m
Discharge : 40 to 50mm
Power : 0.25 to 1.5kw
|
|
| |
|
|
TM Series (Sea Water)
Titanium Material
Vortex Impeller
Solid Passage : 10mm
Capacity : 0.01 to 0.36m³/min
Head : 2m to 15m
Discharge : 40 to 50mm
Power : 0.25 to 0.75kw |
|
|
SF Series
Semi Open Impeller
Solid Passage : 10 to 22mm
Capacity : 0.05 to 1.8m³/min
Head : 2.5m to 45m
Discharge : 50 to 80mm
Power : 0.75 to 11kw |
|
| |
|
|
MG Series
Grinder Impeller
Capacity : 0.015 to 0.32m³/min
Head : 2m to 35m
Discharge : 32 to 50mm
Power : 1.5 to 3.7kw
Power : 0.75 to 15kw
|
|
|
KTX Series (Explosion Proof)
Semi Open Impeller
Solid Passage : 6 to 8mm
Capacity : 0.01 to 1.4m³/min
Head : 2m to 48m
Discharge : 50 to 100mm
Power : 0.4 to 11kw |
|
| |
|
|
AB Series
Semi Open Impeller
Solid Passage : 6 to 8mm
Capacity : 0.015 to 0.32m³/min
Head : 2m to 35m
Discharge : 32 to 50mm
Power : 1.5 to 3.7kw |
|
|
NK Series
Semi Open Impeller
Solid Passage : 6 to 8mm
Capacity : 0.01 to 1.4m³/min
Head : 2m to 48m
Discharge : 50 to 100mm
Power : 0.4 to 11kw |
|
| |
|
| |
|
